120 BLDC 48V 1000W RPM 3100 Rickshaw Motor

120 BLDC 48V 1000W RPM 3100 Rickshaw Motor

Name: 120 BLDC 48V 1000W RPM 3100 Rickshaw Motor
Brand: Changzhou Sino-Pan Electrical Co.,Ltd.
Price: 29 USD
Availability: InStock

29 USD ($)/Piece

Get a Price/Quote

Product Details:

Cooling Method Fan
Voltage 48 Volt (v)
Product Type Synchronous Motor
Output Power 1000 Watt (w)
Protect Feature Other
Phase Three Phase
Efficacy Other
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

120 BLDC 48V 1000W RPM 3100 Rickshaw Motor Price And Quantity

Minimum Order Quantity 200 Piece
Price 29 USD ($)/Piece

120 BLDC 48V 1000W RPM 3100 Rickshaw Motor Product Specifications

Weight 4.8-4.9 Kilograms (kg)
Voltage 48 Volt (v)
Protect Feature Other
Output Power 1000 Watt (w)
Power 1000 Watt (w)
Phase Three Phase
Cooling Method Fan
Speed 3100 RPM
Product Type Synchronous Motor
Efficacy Other
Color golden

120 BLDC 48V 1000W RPM 3100 Rickshaw Motor Trade Information

FOB Port FOB Shanghai
Payment Terms Telegraphic Transfer (T/T)

Product Description

Company Information
Changzhou Sino Pan Electrical Co Ltd supports OEM and ODM

Power	Voltage	Current A	RPM	Height of Magnet	Demagnetization Rate	Temperature Rise	Weight kg
500 W	48 V / 60 V	13.5	3100 r/min	30 x 4 H	Less than 3 percent	Less than 55 C	3.47
650 W	48 V / 60 V	17	3100 r/min	35 x 4 H	Less than 3 percent	Less than 55 C	3.70
800 W	48 V / 60 V	21	3100 r/min	40 x 4 H	Less than 3 percent	Less than 55 C	4.03
1000 W	48 V / 60 V	26	3100 r/min	50 x 4 H	Less than 3 percent	Less than 55 C	4.89
1200 W	48 V / 60 V	32	3100 r/min	60 x 4 H	Less than 3 percent	Less than 55 C	5.59
